Align TB60 Helicopter Kit Only - Align 600 Size RC Electronic Helicopters Unassembled Kit for Adults

Description

• Pro-Level 600-Class RC Helicopter Kit: High-performance platform with no electronics includedideal for advanced pilots who prefer custom setups.
• Flybarless Rotor Head with Torque Tube Tail: Delivers responsive, stable, and aggressive 3D capability using Aligns proven torque tube and FBL system design.
• Rigid Carbon Fiber Frame & CNC Precision: Lightweight yet incredibly strong carbon airframe with CNC aluminum parts for maximum flight performance.
• Quick-Release Battery Tray & Adjustable CG: Modular battery system enables fast swaps; center-of-gravity adjustment improves balance and responsiveness.
• Customizable Component Compatibility: Compatible with a wide range of servos, ESCs, motors & FBL unitstailor to your build preferences.

The Align TB60 Helicopter Kit is a premium 600-class electric heli platform designed for experienced pilots and builders seeking uncompromised performance and customization. Featuring a newly engineered flybarless main rotor head, torque tube tail system, and ultra-rigid carbon fiber frame, the TB60 offers the foundation for high-torque 3D flight and exacting mechanical precision. The modular quick-release battery tray and adjustable CG system provide optimal convenience and in-flight balance, while compatibility with a wide range of servos, motors, and FBL units allows for tailored configurations. Whether you're building your dream heli or upgrading to next-level flight, the TB60 Kit delivers elite-level performance and reliability.

*** Specification:
Length: 1218mm
Height: 353mm
Width: 183mm
Main Blade Length: 600mm
Main Rotor Diameter: 1339mm
Tail Length: 95mm
Tail Rotor Diameter: 253mm
Motor Belt Pulley: 23T
Belt Pulley: 44T
Front Drive Main Shaft: 15T
Main Drive Gear: 62T
Autorotation Tail Drive Gear: 28T
Tail Drive Gear: 23T
Drive Gear Ratio: 7.89:1:5.04
Max RPM(approx.): 2400RPM
Weight: Approx. 1.8kg

*** Accessories:
TB60 Kit Set x 1 set
600 Carbon Fiber Blades x 1 set
95 Carbon Fiber Tail Blades x 1 set
Lube Pack x 1
An Extra set of 600 Carbon Fiber Blade (while supplies last)

*** Radio transmitter and electronic equipment required for assembly
Transmitter(6-channel or more, helicopter system)
Receiver(6-channel or more) or Remoet Receiver
RCC-6CX Intelligent Balance Charger
6S Li-Po 2600 ~ 5200mAh (3300mAh suggestion)
Digital Pitch Gauge
Multi-function Tester
Flybarless System
Brushless Motor x 1
CCPM Brushless Servo x 3
Rudder Brushless Servo x 1
Brushless ESC x 1
