3.6-6V OpenTx Receiver with Two-Way Unidirectional Brushed ESC 4 Servo Outputs Receiver for RC Airplane Boat Model Accessory(2pcs servo)

Description

• Spare Parts: Suitable for repairing or replacing RC boats.
• Ease of use: Easy to install.
• Application: Suitable for different types of boats, such as DIY, simulation.
• Premium Material: Made of good material, durable and wear-resistant, it is a premium replacement part.
• Professional: Compatible with DIY RC Electric Boats

3.6-6V OpenTx Receiver with Two-way Unidirectional Brushed ESC 4 Servo Outputs Receiver

for RC Airplane Boat Model Accessory

This product is compatible with E010 protocol, any controller with multi-protocol tuner (T16, T18, etc.) can select MJXq > E010 in the protocol
Suitable for OpenTx + multi-protocol tuner, but WFT07, Radiolink AT9 remote control can not be used
It is specially designed for small aircrafts of about 100g, suitable for driving 2-way hollow cup motors with 1S lithium battery (motors such as: hollow cup 720, 8520, 1020, N30 strong magnetic motors, etc.) and can also be used as differential boats
Receiver parameters:
E010 protocol: 100 meters on the ground, 150 meters in the air
Adaptation voltage: 3.6-6V (suitable for 1S lithium battery)
4 servo output: boost to 5V to supply stable power to the servo (current 600mah, can bring four 2G servos or two 4.3g servos)
Dual-channel ESC: each channel can output 6A peak value 10A (you can use only one channel, or two channels can be connected in parallel to enhance the current)
ESC output is 3 channel control
(When the 5th pass is at a high position, the 4-way can be used to realize the differential speed. On the contrary, the two-way motor is controlled by the 3-way throttle synchronously.) If you want differential speed: M1 is connected to the right motor, M2 is connected to the left (here, the left and right are relative Airplane looking from back to front)
With runaway protection: Loss of signal, 3 channels output 1000us (the motor will stop), other channels output 1500us,
Receiver board: 39x18.5mm weight 4g (with battery cable)
Pairing method:
1) Press and hold the receiver bind button, power on the receiver, the receiver indicator will flash
2) According to the OpenTX/Er9x control method (as shown in the figure below), the receiver indicator stops flashing, indicating that the code is successfully matched.
The servo socket
